1. No need for large-sized output of DC isolation capacitors, with 0V potential as the reference output;
Excellent low-frequency performance;
Excellent low-frequency performance;
2. Static current: 4mA (PVDD=3.6V, Output=floating)
3. Switching current: 0.01uA
4. Single ended or differential input with built-in input resistor reduces the number of external components,
and the system has excellent noise performance
and the system has excellent noise performance
5. THD+N is only 0.009% (3.6V, 32ohm, 20mW)
6. Power output: 80mW (PVDD=3.6V, fIN=1kHz, RL=32 Ω, THD+N=1%)
160mW (PVDD=5V, fIN=1kHz, RL=32 Ω, THD+N=0.1%)
7. Single power supply: 2.5V-6.0V
8. Protection function: overheat/undervoltage abnormal protection function
9. Lead free packaging, QFN3 × 3-16L
